SPECIFICATIONS

BURNER GAS CONSUMPTION (4x) 0.63 kg/h
TOTAL GAS CONSUMPTION 2.52 kg/h
BTU RATING 108 000
ELECTRICITY 7.5kW, 380V, 3 Phase + N
DIMENSIONS 850 x 900 x 900mm high
WEIGHT 158kg
GRATE DIMENSIONS (4x) 380 x 330mm
INTERNAL OVEN DIM 610 x 700 x 280mm high
RUNNER SPACING 48mm – 4 levels
OVEN TEMP RANGE 50 to 300°C

FEATURES

• Body and panelling manufactured of stainless steel
• Each burner operates independently from each other providing heat economy
• Standby pilot flame on each burner
• Automatic flame failure safety switch (If the flame goes out, gas valve is cut off)
• Top grids manufactured from cast iron
• Supplied with (1x) 2/1 GN oven grid
• Fitted with device leveling legs
