THIS ITEM IS MANUFACTURED ON ORDER – ONCE PAYMENT HAS BEEN MADE – MANUFACTURING TIME 10-15 WORKING DAYS

SPECIFICATIONS

Dimensions: 890mm X 890mm X 1100mm
Power: 18kW, 400V 3-phase N&E
Weight: NW: 145 kg, GW: 155 kg
Capacity: 225 ltr
Oil Jacket Capacity: 60 ltr
Oil Type: Heat Transfer Oil

FEATURES

• Inner pan – 1.6mm grade 304 stainless steel with integral top rim
• Oil jacket – 2mm mild steel with filler tube, breather pipe and drain cock
• Outer casing – 0.9mm stainless steel with 38mm thick insulation
• Lid – 0.9mm grade 304 stainless steel construction, balanced lid with heat insulated handle
• Draw off – 32mm nominal bore outlet controlled by valve with heat insulated handle
• Immersion elements in oil jacket pocket for easy replacement and extended oil life
• Thermostatically controlled with overriding safety thermostat
• It is advisable to drain all the oil from the pot and replenish it with new oil.
• Change oil every 6-9 months, BUT heavy use of the pot, (8-12 hours per day), change oil every 3 months.
